| 1. Application Scope This product specification describes product performance indicators of Lithium-ion cell produced by Shenzhen hrlenergy ltd 2. Model IFR26650-4000mAh-3.2V |
||||
| NO. | Item | Standard | Note | |
| 1 | Standard Capacity | 4000 mAh | 0.2C,( current value of 4000 mA at 1C) | |
| 2 | Minimum Capacity | 3950 mAh | 0.2C | |
| 3 | Standard Voltage | 3.2 V | ||
| 4 | Alternating Internal Resistance | ≤20 mΩ | AC 1kHz measurement at 25±2ºC | |
| 5 | Standard Charge |
Cut-off Voltage |
3.65 V | constant-current charge to 3.65 V at 0.5C, constant voltage charge to stop until 0.01C m A. |
| Charge Current |
2.0 A | |||
| Cut-off Current |
36 mA | |||
| 6 | Max. Charging Current | 3.6 A | ||
| 7 | Standard Discharge |
Discharge Current |
2.0 A | Constant current discharge |
| Discharge Cut off Voltage |
2.5 V | |||
| 8 | Fast Discharge Current | 4 A | This current is the maximum current recommended for the combination of cells, and the specific value should be determined according to the combination structure. The maximum operating current is set at a temperature not exceeding 60 ºC . |
|
| 9 | Max. Continuous Discharge Current |
12A | ||
| 10 | Pulse Discharge Current | 25 A, 5s |
